RATIO TESTER IKD3054 Features
RATIO TESTER IKD3054 Description
The IKD 3054 provides transformation ratio and polarity testing on audio frequency transformers, trigger transformers, pulse transformers, etc. The Tester judges on a 2-circuit transformer. Further, Simultaneous use of two or more of this tester is possible. Combined with IKD3061 L Checker, the IKD 3054 can also provide simultaneous transformation ratio, polarity and inductance testing on a multiple circuit transformer.
RATIO TESTER IKD3054 Specifications
| Power supply | AC100V, 50/60Hz |
|---|---|
| Measuring voltage | 0.5Vrms |
| Test frequency | 1k/10kHz |
| The lowest measurable transformer primary impedance | 0.5ohms (Inductance conversion: 80micronH at 1kHz, 8micronH at 10kHz) |
| Measurement range | 1：0.01~9.99,1：0.001~0.999,1：0.0001~0.0999 (3 ranges) |
| Basic accuracy | + or - 1% |
| Indication of deviation | 0 to + or - 9% (Bar graph) |
| Comparator | 0 to + or - 9% (1% step) |
| Polarity | +/OFF/- |
| Response time | Within 100ms |
| Size | 185×100×215(W×H×D) |
| Color | Light gray |
| Weight | 2.1Kg |
