LAYER SHORT TESTER IKD3031 Features
LAYER SHORT TESTER IKD3031 Description
The IKD 3031 is designed to provide layer withstanding voltage tests on electronic equipment such as transformers, choke coils and solenoids which operate on commercial power line. The Tester detects coronas extending to MHz band as well as judges on load current, and enables to provide a quality assessment with higher reliability than that by conventional testers.
LAYER SHORT TESTER IKD3031 Specifications
| Power supply | AC100 to 125V, 200 to 240V, 50/60Hz |
|---|---|
| Power consumption | 300VA max. |
| Output capacity | 120VA |
| Output frequency | 400/500/600/800/1kHz |
| Output voltage regulation | Less than 3% (at maximum load) |
| Output voltmeter | 300/600/1200V F.S. |
| Output ammeter | 50/100/200/400mA F.S. |
| Corona detection | 20kHz to over 1MHz, Comparator 0 to 9.9% (0.1% step) |
| Timer | 0.5 to 60 sec. |
| Size | 430W×350D×150H(mm) |
| Color | Light gray |
| Weight | Approx. 15Kg |
