L LL TESTER IKD2063A Features
L LL TESTER IKD2063A Description
This instrument is IKD2000 series of inductance tester. For the purpose of IKD2063 maintenance Swaps the main board and the panel of the body. For test conditions and the like almost the same as conventional, numerical value obtained will keep compatibility. Because you are equipped with two-channel display and settings, it can be tested in one of the open inductance and leakage inductance of the transformer. Display is equipped with a digital comparator of the upper and lower limit in the digital 4-digit (maximum display 1999). Setting and that the display is turned on the liquid crystal panel changes are made to key switch, test frequency has been added to 100Hz and 10kHz. In addition, it will be like can be changed individually the frequency setting of L and LL.
L LL TESTER IKD2063A Specifications
Measurement range & level
| Range | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 |
| 100Hz
300Hz LS LP |
1999μH | 19.99mH | 199.9mH | 1.999H | 19.99H | 199.9H | 19.99kH | ||
| 60mA | 10mA | 1mA | 100μA | 100μA | |||||
| 1V | 1V | 1V | 1V | ||||||
| 1kHz LS LP |
199.9μH | 1999μH | 19.99mH | 199.9mH | 1.999H | 19.99H | 199.9H | ||
| 60mA | 10mA | 1mA | 100μA | 100μA | |||||
| 1V | 1V | 1V | 1V | ||||||
| 10kHz LS LP |
19.99μH | 199.9μH | 1999μH | 19.99mH | 199.9mH | 1.999H | 19.99H | ||
| 60mA | 10mA | 1mA | 100μA | 100μA | |||||
| 1V | 1V | 1V | 1V |
| Accuracy | LS 0.8%+3digits(D≦1) LP 1%+3digits(D≦1) |
|---|---|
| Measurement period | Less than 500ms. |
| Indication | Digital indication(1999 max.) |
| Comparator | Digital setting, upper and lower limit setting. (lower limit value ≦ indication value ≦ upper limit value) is good. |
| Measurement frequency accuracy | Less than ±0.1% |
| Power source | AC100V±10V 50/60Hz Less than 0.5A |
| Dimensions | 480×455×100(mm:W×H×D) Rack mount |
| Color | Light gray |
| Weight | Approx 10kg |
