SWITCHING TRANSFORMER GENERAL TESTING EQUIPMENT IKD2000SW-MINI Features
SWITCHING TRANSFORMER GENERAL TESTING EQUIPMENT IKD2000SW-MINI Description
This equipment is designed to provide a series of testing, i.e., withstanding voltage, transformation ratio (5 circuits), polarity (5 circuits), inductance and leakage inductance testing and judgement on switching and low frequency transformers. The system is equipped with CORE CONTACT CHECK function to assure the testing be accurately done on cores. The controller can store 100 of different programs.
SWITCHING TRANSFORMER GENERAL TESTING EQUIPMENT IKD2000SW-MINI Specifications
Ratio Tester IKD3053（2 sets）
| Primary applied voltage | 0.5Vrms |
|---|
| Primary applied frequency | 1k/10kHz |
|---|
| Measurement range | 1：0.00010 to 9.99900 |
|---|
| Comparator | ±0 to ±99.9%(0.1% step) |
|---|
L,LL Tester IKD2063
| Test frequency | 300Hz,1kHz |
|---|
| Measurement circuit modes | LS,LP |
|---|
| Measurement range | 0.1μH to 2000H |
|---|
| Comparator | Digital setting, 4 digits, upper and lower limit setting |
|---|
| Indication | Digital indication of 4 digits (2024 max.) |
|---|
Controller IKD2213
| Step number | Max 30steps |
|---|
| Timer | 0.1 to 150sec |
|---|
| Program | Max. 100 programs storable |
|---|
Withstanding Voltage Tester IKD2306
| Output voltage | AC0 to 5kV, 500/800/1200/1800V (2 stages) |
|---|
| Output capacity | 500VA (100mA max.) |
|---|
| Power-on | Zero cross power-on |
|---|
| Cutoff current | 0.5/1/2/5/10/100mA, 6 ranges |
|---|
| Withstanding voltage between connections | AC6kV, 50/60Hz |
|---|
Dimensions
| Dimensions | 525W×620D×990H(mm) |
|---|
