SWITCHING TRANSFORMER GENERAL TESTING EQUIPMENT IKD2000SW-9C Features
SWITCHING TRANSFORMER GENERAL TESTING EQUIPMENT IKD2000SW-9C Description
This equipment is designed to provide a series of testing, i.e., withstanding voltage, insulation resistance, impulse, transformation ratio (9 circuits), polarity (9 circuits) inductance and leakage inductance testing and judgement on switching and low frequency transformers. A DCR test can optionally be supported. The system is equipped with two sets of test terminals (right and left) which provide a STAND-BY function. During testing, one of the two sets is free and ready to connect to the transformer subsequently tested (The STAND-BY function by change-over between right and left). The withstanding voltage testing and insulation resistance testing can be done on any windings. The system is equipped with CORE CONTACT CHECK function to assure that the testing be accurately done on core. The controller can store 256 different programs. The system can further be set up as a testing system according to functions and purposes. Equipped with switching units in the rack, this system is a compact and improved version of the standard system.
SWITCHING TRANSFORMER GENERAL TESTING EQUIPMENT IKD2000SW-13C Specifications
Withstanding Voltage Tester IKD2011
| Output voltage | AC0 to 5kV, presettable in 2 stages |
|---|
| Cutoff current | 0.5/1/2/5/10/100mA,6 ranges |
|---|
| Output capacity | 500VA (100mA max.) |
|---|
| Power-on | Zero cross power-on |
|---|
Insulation Tester IKD2022
| Measurement range | 100k ohms to 500G ohms |
|---|
| Test voltage | DC100,250,500,1000V (4 ranges) |
|---|
| Comparator | Digital setting, 3 digits, lower limit setting |
|---|
| Indication | Digital indication of 3 digits |
|---|
Impulse Tester DW9505
Ratio Tester IKD3053（2 sets）
| Primary applied voltage | 0.5Vrms |
|---|
| Primary applied frequency | 1k/10kHz |
|---|
| Measurement range | 1：0.00010 to 9.99900 |
|---|
| Comparator | ±0 to ±99.9%(0.1% step) |
|---|
L,LL Tester IKD2063
| Test frequency | 300Hz,1kHz |
|---|
| Measurement circuit modes | LS,LP |
|---|
| Measurement range | 0.1μH to 2000H |
|---|
| Comparator | Digital setting, 4 digits, upper and lower limit setting |
|---|
| Indication | Digital indication of 4 digits (2024 max.) |
|---|
DCR Tester IKD2071
| Measurement range | Range1：0~124.99mΩ 100mA max
Range2：0~1249.9mΩ 100mA max
Range3：0~12.499Ω 100mA max
Range4：0~124.99Ω 1mA max
Range5：0~1249.9Ω 1mA max
Range6：0~12.499KΩ 10μA max
Range7：0~124.99KΩ 10μA max
|
|---|
| Measuring voltage | 5VDC(at time of releasing) |
|---|
| Sampling time | 100ms |
|---|
| Measuring time | Less than 200ms |
|---|
| Power | AC100V 50/60Hz 100VA |
|---|
| Others | Copper temperature compensation function. A thermometer and hygrometer equipped. |
|---|
Controller IKD2213
| Step number | Max. 50steps |
|---|
| Timer | 0.1 to 150sec. |
|---|
| Program | Max. 256 programs storable |
|---|
Switching Unit IKD2111(2 Sets)
| Withstanding voltage between connections | AC6kV,50/60Hz |
|---|
| Insulation resistance | Over 2000M ohms, DC1000V |
|---|
Dimensions
| Dimensions | 540W×770D×1,750H(mm) |
|---|
