IKD2000P

POWER TRANSFORMER GENERAL TESTING EQUIPMENT IKD2000P Features

POWER TRANSFORMER GENERAL TESTING EQUIPMENT IKD2000P Description

This equipment is designed to provide a series of testing, i.e., withstanding voltage, insulation resistance, layer withstanding voltage, no-load loss, no-load voltage (11 circuits) and polarity (11 circuits) testing and judgement on small-sized power transformers. A DCR test can optionally be supported. The system is equipped with two sets of test terminals (right and left) which provide a STAND-BY function. During testing, one of the two sets is free and ready to connect to the transformer subsequently tested (The STAND-BY function by change-over between right and left). The withstanding voltage testing and insulation resistance testing can be done on any windings. The system is equipped with CORE CONTACT CHECK function to assure that the testing be accurately done on core. The system can further be set up as a testing system according to functions and purposes.

POWER TRANSFORMER GENERAL TESTING EQUIPMENT IKD2000P Specifications

Withstanding Voltage Tester IKD2011

Output voltage	AC0 to 5kV, presettable in 2 stages
Cutoff current	0.5/1/2/5/10/100mA, 6 ranges
Output capacity	500VA (100mA max.)
Power-on	Zero cross power-on

　　　
Insulation Tester IKD2022

Output voltage	100k ohms to 500G ohms
Test voltage	DC100,250,500,1000V (4 ranges)
Comparator	Digital setting, 3 digits, lower limit setting
Indication	Digital indication of 3 digits

　　　
Layer Short Tester IKD3031

Output voltage	AC0 to 1200V
Output frequency	400/500/600/800/1000Hz
Output capacity	120VA

　　　
Multi Meter IKD2043

No-load current	16,32,64,128,256,512,1024,2048mA
Primary voltmeter	8,16,32,64,128,256,512,750V
Secondary voltmeter	8,16,32,64,128,256,512,750V
Polarity	12 circuits
Primary power source	AC100V, 50/60Hz
Power consumption	600VA
No-load loss	voltage range 2V to 750V curennt range 0 to 2.048A

　　　
DCR Tester IKD2071

Measurement range	Range1：0~124.99mΩ 100mA max Range2：0~1249.9mΩ 100mA max Range3：0~12.499Ω 100mA max Range4：0~124.99Ω 1mA max Range5：0~1249.9Ω 1mA max Range6：0~12.499KΩ 10μA max Range7：0~124.99KΩ 10μA max
Measuring voltage	5VDC(at time of releasing)
Sampling time	100ms
Measuring time	Less than 200ms
Power	AC100V 50/60Hz 100VA
Others	Copper temperature compensation function. A thermometer and hygrometer equipped.

　　　
Controller IKD2213

Step number	Max.50 steps
Timer	0.1 to 150sec.
Program	Max. 256 programs storable

　　　
Switching Unit IKD2111(2sets)

Withstanding voltage between connections	AC6kV 50/60Hz
Insulation resistance	Over 2000M ohms , DC1000V

　　　
Dimensions

Dimensions	540W×770D×1,750H(mm)
