POWER TRANSFORMER GENERAL TESTING EQUIPMENT IKD2000P-MINI Features
POWER TRANSFORMER GENERAL TESTING EQUIPMENT IKD2000P-MINI Description
This Equipment is designed to provide a series of testing, i.e., withstanding voltage, layer withstanding voltage, no-load current, no-load loss, no-load voltage (5 circuits) and polarity (5 circuits) testing and judgement on small-sized power transformers. This system is equipped with CORE CONTACT CHECK function to assure that the testing be accurately done on cores. The controller can store 100 of different programs.
POWER TRANSFORMER GENERAL TESTING EQUIPMENT IKD2000P-MINI Specifications
Multi Meter IKD2043
| No-load current | 16,32,64,128,256,512,1024,2048mA |
|---|
| Primary voltmeter | 8,16,32,64,128,256,512,750V |
|---|
| Secondary voltmeter | 8,16,32,64,128,256,512,750V |
|---|
| Polarity | 12
circuits |
|---|
| Primary power source |
AC100V, 50/60Hz |
|---|
| Power consumption | 600VA |
|---|
| No-load loss |
voltage range 2V to 750V
curennt range 0 to 2.048A |
|---|
Layer Short Tester IKD3031
| Output voltage |
AC0 to 1200V |
|---|
| Output frequency |
400/500/600/800/1000Hz |
|---|
| Output capacity | 120VA |
|---|
Controller IKD2214
| Step number | Max.30 steps |
|---|
| Timer | 0.1 to
150sec. |
|---|
| Program | Max.256 programs storable |
|---|
Withstanding Voltage Tester IKD2306
| Output voltage | AC0 to 5kV, 500/800/1200/1800V (2 stages) |
|---|
| Output capacity | 500VA (100mA max.) |
|---|
| Power-on | Zero cross power-on |
|---|
| Cutoff current | 0.5/1/2/5/10/100mA, 6 ranges |
|---|
| Withstanding voltage between connections | AC6kV, 50/60Hz |
|---|
Dimensions
| Dimensions | 525W×620D×990H(mm) |
|---|
