TRANSFORMER GENERAL TESTING EQUIPMENT IKD1000 Description
The IKD 1000 is one of the IKD's highest-quality models with high performance and functionality. The IKD 1000 enables to include any tester necessary for testing on low frequency transformers, and to support tests on most of the transformers. The IKD 1000 provides testing on the transformers having maximum of 32 terminals without having any restriction on the difference in circuits. The IKD 1000 also provides 4-terminal measurement via any paired terminal as necessary. Withstanding voltage tests and insulation tests can be done on any winding. The IKD 1000 is equipped with CORE CONTACT CHECK function to assure accuracy of the tests on core. About 100 testing specifications can be registered in a built-in nonvolatile memory.
Though IKD 1000 is digitally controlled, it is designed for easy operation. The testing specifications are centrally controlled by a controller which can provide complete test conditions and a consistent testing specification.
The IKD 1000 can also be equipped with two sets of test terminals (right and left) which provide a STAND-BY function. During the testing, one of the terminals is free and ready to connect to a transformer for the subsequent testing (STAND-BY function by change-over between right and left).
Composed of a lot of measuring instruments and relays, the IKD 1000 requires substantial knowledge and much labor for maintenance and repairing. Nevertheless, the IKD 1000 has a reliable self diagnosis function which assures its stable operation in production lines.
A jig is indispensable for rapid operation of the testing system. The IKD 1000 is normally equipped with a jig control system which allows for an improved test environment. When combined with an external personal computer, this testing system can provide recording and storing test data and specification data in floppy disks. With this arrangement, test data can also be printed out.
TRANSFORMER GENERAL TESTING EQUIPMENT IKD1000 Specifications
Withstanding Voltage Tester IKD1010
Insulation Tester IKD1020
Layer Short Tester IKD1030
Multi Meter IKD1040
Power Supply Unit
Secondary Voltmeter
Ratio Tester IKD1051
LCZ Meter IKD1064
DCR Tester IKD1071
Controller IKD1200
Switching Unit IKD1100
Dimensions
| Output voltage | 0 to 5.115kV, 5V resolution |
|---|---|
| Output transformer capacity | 500VA |
| Load drop | Less than + or - 1% at 5kV with 400kOhms (50Hz) |
| Output cutoff setting | 0.1 to 10.0mA, 0.1mA resolution |
| Output cutoff ammeter | 0 to 40.00mA, 0.005mA resolution (Average value full wave rectification, rms calibration) |
| Output voltmeter |
0 to 6kV F.S., 1V resolution, 3 or 4 digit indication (average value full wave rectification, rms value calibration) |
| Output frequency | 50 to 533Hz, sine wave, 1Hz resolution |
| Power-on |
A voltage reaches the set-up voltage after RT has passed since 0V (RT: 0 to 10.0 sec.) |
Insulation Tester IKD1020
| Measurement range | 100k ohms to 500G ohms |
|---|---|
| Indication | Digital indication of 3 or 4 digits |
| Test voltage | DC100, 250, 500 and 1000V (4 ranges) |
Layer Short Tester IKD1030
| Output voltage | 0 to 1200V (3 ranges) |
|---|---|
| Output capacity | 200VA continuous |
| Output voltmeter | 0 to 2000V (3 ranges) (Average value full wave rectification, rms calibration) |
| Output ammeter | 0 to 800mA (3 ranges)(Average value full wave rectification, rms calibration) |
| Output frequency | 400 to 2.5kHz, sine wave, 10Hz resolution |
| Power-on | A voltage reaches the set-up voltage after RT has passed since 0V (RT: 0 to 10.0 sec.) |
Multi Meter IKD1040
Power Supply Unit
| Output voltage | 0 to 511.5V (3 ranges) |
|---|---|
| Output frequency | 45 to 533 Hz, sine wave, 1Hz resolution |
| Output capacity | 200VA continuous |
| Output ammeter | 0 to 2048mA (10 ranges)(Rms detection, crest factor less than 3) |
| Output voltmeter | 0 to 1024V (8 ranges)(Average value full wave rectification, rms calibration) |
| Output wattmeter | 0 to 2097W |
| Power-on |
A voltage reaches the set-up voltage after RT has passed since 0V (RT: 0.1 to 10.0 sec.) |
Secondary Voltmeter
| Measurement range | 0 to 1000V (4 ranges) |
|---|---|
| Detection (AC) |
Average value detection, rms calibration; rms detection, rms
calibration; peak to peak value detection, peak to peak value
calibration DC volt measurement |
| DC volt measurement Coupling | AC/DC switchable (DC superimpose: 80V max.) |
Ratio Tester IKD1051
| Test frequency | 100/1k/10kHz/100kHz less than ±0.1% |
|---|---|
| Measurement range | 1：0.000000
to 0.039999 1：0.00000 to 0.39999 1：0.0000 to 3.9999 1：0.000 to 39.999 (4ranges) |
| Measuring voltage | 0.5Vrms/0.05Vrms(Range4) |
LCZ Meter IKD1064
| Test frequency | 40Hz to 200kHz(1mHz~10Hz step) |
|---|---|
| Measuring voltage | 5mV to 5Vrms,1mVrms step |
| Measurement range | ±(0.00000[unit]
to 9.99999G[unit]) D：±(0.00000 to 9.99999) Q：±(0.00 to 9999.99) |
| Test time | 2ms(1kHz,FAST,Display OFF,Representative value) |
| Others | Built-in HIOKI IM3523(LCR METER), GPIB-OPT Interface IKD 1212 is required. |
DCR Tester IKD1071
| Measurement range | 0 to 125k ohms (5 ranges, 1m ohms resolution at min. range) |
|---|---|
| Others |
Copper temperature compensation function. A thermometer and hygrometer equipped. |
Controller IKD1200
| Program | Perfect setting and storage of test specifications |
|---|---|
| Memory | 4Mbyte |
| Timer | 0 to approx. 10 min (minimum 0.1 sec step) |
| Step number | Max. 999 steps |
Switching Unit IKD1100
| Withstanding voltage between connections | AC6kV 50/60Hz |
|---|---|
| Insulation resistance | More than 2000M ohms , DC1000V |
Dimensions
| Dimensions | 530W×750D×1,640H (mm) (2 sets) |
|---|
